SMC IP8000 IP8100 Smart Valve Positioner with 4-20mA Input

1
MOQ
US $888.00 - 1088.00/ Unit
harga
SMC IP8000 IP8100 Smart Valve Positioner with 4-20mA Input
fitur Galeri Deskripsi Produk Quote request suatu
fitur
Spesifikasi
Arus input: 4-20 ma dc (standar)
Pengulangan: Dalam ± 0,5% FS
Aliran output: ≥ 80 L/mnt (ANR) pada pasokan 0,14 MPa; ≥ 200 L/menit pada 0,4 MPa
Kisaran Suhu Ambient & Fluida:: -20 ° C hingga 80 ° C (area tidak berbahaya)
Berat: kira -kira. 2,4 kg
Perlindungan masuk: IP65
Konstruksi anti ledakan: Ya
Menyoroti:

Smart valve positioner 4-20mA input

,

Pneumatic control valve positioner

,

SMC IP8000 valve positioner
Informasi dasar
Nama merek: SMC
Nomor model: IP8000 IP8100 IP8001 IP8101
Dokumen: Company profile Xiangjing (...ts.pdf
Syarat-syarat pembayaran & pengiriman
Kemasan rincian: Karton + Kotak Kayu + Perlindungan
Waktu pengiriman: 90 hari kerja
Syarat-syarat pembayaran: T/t
Menyediakan kemampuan: 500 unit per tahun
Deskripsi Produk
SMC Solenoid Valve IP8000 IP8100 IP8001 IP8101 Smart Valve Positioner
Product Overview

The SMC IP8000-IP8101 series offers smart electro-pneumatic positioners for precise industrial control. With customizable options including explosion-proof housing, stainless steel construction, and PID control, these positioners adapt to diverse environments. The IP8101 model adds auto-calibration and alarm output functions for enhanced reliability.

Technical Specifications
Attribute Value
Input Current 4-20 mA DC (Standard)
Repeatability Within ±0.5% F.S.
Output Flow ≥ 80 L/min (ANR) at 0.14 MPa supply; ≥ 200 L/min at 0.4 MPa
Ambient & Fluid Temperature Range -20 °C to 80 °C (non-hazardous areas)
Weight approx. 2.4 kg
Ingress Protection IP65
Explosion-Proof Construction Yes
Model Comparison
Parameter IP8000/IP8100 IP8001/IP8101
Input Signal 4-20mA DC 4-20mA DC (HART)
Temperature Range -35℃ to +60℃ -20℃ to +80℃
Repeatability ±0.5%F.S. ±0.5%F.S.
Air Consumption 3LPM (Sup=1.4kgf/cm²) 5LPM (Sup=1.4kgf/cm²)
Key Features
  • Customizable stroke ranges (0-100mm)
  • Corrosion-resistant materials for chemical plants
  • Remote monitoring via HART/RS485
  • Low-vibration design for marine applications
Applications
  • Offshore oil drilling platforms
  • HVAC systems in clean rooms
  • Paper mill pulp processing
